Description

Siemens introduces PN Series Load Centers – a new high quality and feature-rich line of load center products to meet applications for virtually every need. The PN Series load center provides maximum flexibility in combination with labor saving features to aid the contractor while installing the product. PN load centers accept the plug-on neutral breakers, patented insta-wire neutral/ground system, convertibility, copper bussing and mounting tabs on the trim – these features were specifically engineered to decrease installation time and increase flexibility.

• Features siemens plug-on neutral, for simple quick installation, that is spacious with over 4 inches of wire bending space and a secure reliable installation method
• Single phase load center
• Tin plated copper bus
• NEMA type 1 enclosure
• Interrupt rating 22000 AIC

Specifications:

• Brand Name: Siemens
• Sub Brand: PN Series
• Amps: 100 amps
• Volts: 120/240 V
• Number of Spaces: 30 space
• Maximum Number of Circuits: 30 circuits
• Mounting Type: Combination Mount
• Product Type: Circuit Breaker Panel
• Depth: 3.875 in.
• UL Listed: Yes
• Circuit Protection Type: Main Breaker
• Height: 30 in.
• Width: 14.25 in.
• Indoor or Outdoor: Indoor
